GROMACS on AWS: compiling against CUDA

If you want to compile GROMACS to run on a GPU Amazon Web Services EC2 instance, please first read these instructions on how to compile GROMACS on an AMI without CUDA. These instructions then explain how to install the CUDA toolkit and compile GROMACS against it.

The first few steps are loosely based on these instructions, except rather than download the NVIDIA driver, we shall download the CUDA toolkit since this includes an NVIDIA driver. First we need to make sure the kernel is updated

sudo yum install kernel-devel-`uname -r`
sudo reboot

Safest to do a quick reboot here. Assuming you are in your HOME directory, move into your packages folder.

cd packages/

And download the CUDA toolkit (version 7.5 at present)

wget http://developer.download.nvidia.com/compute/cuda/7.5/Prod/local_installers/cuda_7.5.18_linux.run
sudo /bin/bash cuda_7.5.18_linux.run

It will ask you to accept the license and then asks you a series of questions. I answer Yes to everything except installing the CUDA samples. Now add the following to the end of your ~/.bash_profile using a text editor

export PATH; PATH="/usr/local/cuda-7.5/bin:$PATH"
export LD_LIBRARY_PATH; LD_LIBRARY_PATH="/usr/local/cuda-7.5/lib64:$LD_LIBRARY_PATH"

Now we can build GROMACS against the CUDA toolkit. I’m assuming you’ve already downloaded a version of GROMACS and probably installed a non-CUDA version of GROMACS (so you’ll already have one build directory). Let’s make another build directory. You can call it what you want, but some kind of consistent naming can be helpful. The -j 4 flag assumes you have four cores to compile on – this will depend on the EC2 instance you have deployed. Obviously the more cores, the faster, but GROMACS only takes minutes, not hours.

mkdir build-gcc48-cuda75
cd build-gcc48-cuda75
cmake .. -DGMX_BUILD_OWN_FFTW=ON -DCMAKE_INSTALL_PREFIX=/usr/local/gromacs/5.0.7-cuda/  -DGMX_GPU=ON -DCUDA_TOOLKIT_ROOT_DIR=/usr/local/cuda
make -j 4
sudo make install

To load all the GROMACS tools into your $PATH, run this command and you are done!

source /usr/local/gromacs/5.0.7-cuda/bin/GMXRC

If you run this mdrun binary on a GPU instance it should automatically detect the GPU and run on it, assuming your MDP file options support this. If it does you will see this zip by in the log file as GROMACS starts up

1 GPU detected:
  #0: NVIDIA GRID K520, compute cap.: 3.0, ECC:  no, stat: compatible

1 GPU auto-selected for this run.
Mapping of GPU to the 1 PP rank in this node: #0

Will do PME sum in reciprocal space for electrostatic interactions.

Depending on the size and forcefield you are using you should get a speedup of at least a factor two, and realistically three, using a GPU in combination with the CPUs. For example, see these benchmarks.

2 thoughts on “GROMACS on AWS: compiling against CUDA

  1. Charlie says:

    Hi Phil,

    I’ve found your posts on getting Gromacs running on EC2 great, but I’ve hit a snag at this stage- getting a GPU instance up and running. When I when I try to run the installer (sudo /bin/bash cud_7.5.18_linux.run) it fails with the message:

    Installing the NVIDIA display driver…
    The driver installation is unable to locate the kernel source. Please make sure that the kernel source packages are installed and set up correctly.
    If you know that the kernel source packages are installed and set up correctly, you may pass the location of the kernel source with the ‘–kernel-source-path’ flag.

    ===========
    = Summary =
    ===========

    Driver: Installation Failed
    Toolkit: Installation skipped
    Samples: Not Selected

    Logfile is /tmp/cuda_install_2805.log

    Have you encountered such a thing yourself? I have done a bit of digging and it seems it may have something to do with deactivating nouveau – but I quickly ran into a quagmire of random and confusing suggestions when I googled further. My instance is a g2.2xlarge and the AIM ID is amzn-ami-hvm-2016.03.1.x86_64-gp2 (ami-b0ac25c3)

    Any suggestions much appreciated!

  2. Charlie says:

    Hi Phil,

    I’ve found your posts on getting Gromacs running on EC2 great, but I’ve hit a snag at this stage- getting a GPU instance up and running. When I when I try to run the installer (sudo /bin/bash cud_7.5.18_linux.run) it fails with the message:

    Installing the NVIDIA display driver…
    The driver installation is unable to locate the kernel source. Please make sure that the kernel source packages are installed and set up correctly.
    If you know that the kernel source packages are installed and set up correctly, you may pass the location of the kernel source with the ‘–kernel-source-path’ flag.

    ===========
    = Summary =
    ===========

    Driver: Installation Failed
    Toolkit: Installation skipped
    Samples: Not Selected

    Logfile is /tmp/cuda_install_2805.log

    Have you encountered such a thing yourself? I have done a bit of digging and it seems it may have something to do with deactivating nouveau – but I quickly ran into a quagmire of random and confusing suggestions when I googled further. My instance is a g2.2xlarge and the AIM ID is amzn-ami-hvm-2016.03.1.x86_64-gp2 (ami-b0ac25c3)

    Any suggestions much appreciated!
